Boron Carbide Powder
Application: For the lapping of hard material like sapphire, ceramic, cemented carbide, harden steel etc.
Type | Particle size at 3% point | Particle size at 50% point | Particle size at 94% point |
F230 | 82 | 53.0±3.0 | 34 |
F240 | 70 | 44.5±2.0 | 28 |
F280 | 59 | 36.5±1.5 | 22 |
F320 | 49 | 29.2±1.5 | 16.5 |
F360 | 40 | 22.8±1.5 | 12 |
F400 | 32 | 17.3±1.0 | 8 |
F500 | 2 | 12.8±1.0 | 5 |
F600 | 19 | 9.3±1.0 | 3 |
F800 | 14 | 6.5±1.0 | 2 |
F1000 | 10 | 4.5±0.8 | 1 |
F1200 | 7 | 3.0±0.5 | 1 (80%) |
Recommended Vehicle and Additive:
Water soluble vehicle: WS-03C P42
Oil base vehicle: OBV-3 P42
Lapping slurry suspension additive: Vector HTS 1.3EU / Challenge 543-HT P43
Lapping slurry dispersion additive: Vector HTN / Challenge 550-HT P46
Lapping slurry anti-rust additive: AR-100 / AR-200
Packing Info:
0.5kg/bag, 1kg/bag, 2kg/bag, 5kg/bag
